HIKVISION

DS-2CD1023G0E-I

2 MP Fixed Bullet Network Camera

The HIK DS-2CD1023G0E-I is a high-performance 2MP IR Network Bullet Camera designed for reliable, round-the-clock security monitoring. Equipped with advanced 1/2.8" progressive scan CMOS technology, it delivers crisp Full HD video surveillance. This camera features powerful infrared technology providing up to 30 meters of night vision, ensuring clear footage even in complete darkness. With options for a 2.8mm or 6mm lens, it offers flexible viewing angles tailored to your specific monitoring needs. Its durable, weather-resistant bullet form factor makes it an excellent choice for both indoor and outdoor installations.

View User Manuals

Available models:

DS-2CD1023G0E-I (2.8 MM)

DS-2CD1023G0E-I (4 MM)

DS-2CD1023G0E-I (6 MM)

1 YEAR WARRANTY

Installation Available

Enhance your property’s security with the HIK DS-2CD1023G0E-I 2MP Network Bullet Camera. This camera captures high-quality video analytics and surveillance footage with a clear 1080p resolution. It is engineered with efficient H.265+ compression technology, which significantly reduces bandwidth and storage requirements without compromising video quality. Built to withstand various environmental conditions, its robust housing makes it highly durable for outdoor perimeter monitoring. The integrated infrared LEDs automatically adapt to low-light conditions, delivering exceptional black-and-white images up to 30 meters away. Whether managing a retail store, office space, or residential property, this network camera provides dependable, high-definition coverage day and night.

Key Features:

Full HD Clarity: 2 Megapixel resolution delivers sharp and detailed 1080p video quality.
Flexible Monitoring: Available in 2.8mm and 6mm focal length lens options to adjust your field of view.
Advanced Night Vision: Integrated smart IR LEDs provide clear visibility up to 30 meters in pitch darkness.
Efficient Storage: Utilizes H.265+ compression to save storage space and network bandwidth.
Reliable Build: Engineered in a classic bullet form factor suitable for outdoor security setups.
Peace of Mind: Includes a 1-Year Warranty for guaranteed product reliability.

Camera

Image Sensor	1/2.7" Progressive Scan CMOS
Max. Resolution	1920 × 1080
Min. Illumination	Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
Shutter Time	1/3 s to 1/100, 000 s
Day & Night	IR cut filter
Angle Adjustment	Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°

Lens

Focal Length & FOV	2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2° 4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
Lens Mount	M12
Iris Type	Fixed
Aperture	F2.0

Video

Main Stream	50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream	50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
Video Compression	Main Stream: H.265/H.264/H.264+/H.265+ Sub-Stream: H.265/H.264/MJPEG
Video Bit Rate	32 Kbps to 8 Mbps
H.264 Type	Baseline Profile/Main Profile/High Profile
H.265 Type	Main Profile
Region of Interest (ROI)	1 fixed region for main stream

Network

Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
Simultaneous Live View	Up to 6 channels
API	Open Network Video Interface, ISAPI
User/Host	Up to 32 users. 3 levels: administrator, operator and user
Client	iVMS-4200, Hik-Connect
Web Browser	Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+


Image Settings	Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
Day/Night Switch	Day, Night, Auto, Schedule
Wide Dynamic Range (WDR)	Digital WDR
SNR	≥ 52 dB
Image Enhancement	BLC, 3D DNR

Interface

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

General

Power	12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
Dimension	177.6 mm × 66.2 mm × 67.8 mm (7.0" × 2.6" × 2.7")
Package Dimension	216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6") Approx. 270 g (0.6 lb.)
With Package Weight	Approx. 490 g (1.1 lb.)
Storage Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
Startup and Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
Language	English, Ukrainian
General Function	Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
